Allen-Bradley 1769-SDN User Manual

1 Publication 1769-UM009B-EN-P - May 2002
Chapter 6
Using the 1769-SDN Scanner Module with
CompactLogix Controllers
This chapter contains an example where the 1769-SDN scanner
module is used with a 1769-L30 controller and a 1769-ADN adapter
module.
The following table describes what this chapter contains and where to
find specific information.
System Diagram
The following system diagram shows the example DeviceNet
network.
Figure 6.1 1769-SDN DeviceNet Scanner System with a 1769-ADN Adapter
For information about See page
System Diagram 6-1
Purpose 6-2
Scope 6-2
Configuring The DeviceNet System using RSNetWorx 6-2
Creating a Project for the 1769-L30 CompactLogix Controller 6-10
MS
IO
NS
DIAG
1769-L30 1769-IQ16 1769-OV16 1769-PA2 1769-SDN 1769-ECR
1769-ADN 1769-IA16 1769-OB16 1769-PA2 1769-IF4 1769-OF2 1769-ECR
DeviceNet
Notebook Computer with:
• RSLogix 5000, Version 8.02 or higher
• RSNetWorx, Version 3.00 or higher
• RSLinx, Version 2.30 or higher
• 1784-PCID DeviceNet Interface card (or a 1770-KFD
and a comm. Port)
DeviceNet
Power Supply
Allen-Bradley Drives
