Publication 1769-UM009B-EN-P - May 2002
4-2 Configuring the DeviceNet Network
Installing the Software
Install RSLinx and RSNetWorx.
For both of these software packages:
1. Insert the software CD-ROM in the drive.
The CD-ROM supports Windows Autorun. If you have Autorun
configured, the installation will automatically start when you
insert the CD-ROM in your drive. If you do not have Autorun
configured, perform steps 2 and 3.
2. From the Windows Start menu, select Run.
3. Browse for the Setup program on the CD-ROM and open it.
4. Follow the prompts that appear on the screen as you install the
software.
After software installation is complete, you will use RSLinx to
configure your DeviceNet driver and RSNetWorx to configure the
network.
Using RSLinx to Configure
Your DeviceNet Driver
1. Start RSLinx. The RSLinx main window will open.
