Rockwell Automation Publication 22C-UM001J-EN-E - January 2017 103
Programming and Parameters Chapter 3
d304 [PID Setpnt Displ] Related Parameter(s): A152
Displays the active PID Setpoint value.
Values Default: 0.0%
Min/Max: 0.0/100.0%
Display: 0.1%
d305 [Analog In 1] Related Parameter(s): T069-T071
Displays the status of Analog Input 1.
Values Default: 0.0%
Min/Max: 0.0/120.0%
Display: 0.1%
d306 [Analog In 2] Related Parameter(s): T073...T075
Displays the status of Analog Input 2.
Values Default: 0.0%
Min/Max: 0.0/120.0%
Display: 0.1%
d307 [Fault 1 Code] Related Parameter(s): A197
A code that represents a drive fault. The codes will appear in these parameters in the order they occur (d307 [Fault 1 Code] = the most recent fault). Repetitive faults will only be
recorded once. Refer to Chapter 4 for fault code descriptions.
Values Default: Read Only
Min/Max: 0/122
Display: 1
d308 [Fault 2 Code] Related Parameter(s): A197
A code that represents the second most recent drive fault. The codes will appear in these parameters in the order they occur (d307 [Fault 1 Code] = the most recent fault). Repetitive
faults will only be recorded once. As faults occur, this parameter will be overwritten by [Fault 1 Code]. The value of this parameter is then moved to [Fault 3 Code].
Refer to Chapter 4 for fault code descriptions.
Values Default: Read Only
Min/Max: 0/122
Display: 1
d309 [Fault 3 Code] Related Parameter(s): A197
A code that represents the third most recent drive fault. The codes will appear in these parameters in the order they occur (d307 [Fault 1 Code] = the most recent fault). Repetitive
faults will only be recorded once. As faults occur, this parameter will be overwritten by [Fault 2 Code].
Refer to Chapter 4
for fault code descriptions.
Values Default: Read Only
Min/Max: 0/122
Display: 1
d310 [Fault 1 Time-hr] Related Parameter(s): A195, d316
Displays the value of the d316 [Elapsed Time-hr] parameter when the fault occurred.
Values Default: Read Only
Min/Max: 0/32767 Hr
Display: 1 Hr
