Supplemental Drive Information Appendix A
Agency Certification
Protection
Environment
Specification
Listed to UL508C and CAN/CSA-22.2
Certified to AS/NZS, 1997 Group 1, Class A
Marked for all applicable European Directives
EMC Directive (2014/30/EU)
EN 61800-3
Low Voltage Directive (2014/35/EU)
EN 61800-5-1
The drive is also designed to meet the appropriate portions of the following specifications:
NFPA 70 - US National Electrical Code
NEMA ICS 3.1 - Safety standards for Construction and Guide for Selection, Installation and Operation of
Adjustable Speed Drive Systems.
IEC 146 - International Electrical Code.
Specification
Bus Overvoltage Trip: 200...240V AC Input: 405V DC bus voltage
(equivalent to 290V AC incoming line)
380...460V AC Input: 810V DC bus voltage
(equivalent to 575V AC incoming line)
Bus Undervoltage Trip: 200...240V AC Input: 210V DC bus voltage
(equivalent to 150V AC incoming line)
380...480V AC Input: 390V DC bus voltage
(equivalent to 275V AC incoming line)
Power Ride-Thru: 100 milliseconds
Logic Control Ride-Thru: 0.5 seconds minimum, 2 seconds typical
Electronic Motor Overload Protection: Provides class 10 motor overload protection according to NEC
article 430 and motor over-temperature protection according
to NEC article 430.126 (A) (2). UL 508C File 29572.
Overcurrent: 180% hardware limit, 220% instantaneous fault
Ground Fault Trip: Phase-to-ground on drive output
Short Circuit Trip: Phase-to-phase on drive output
Specification
Altitude: 1000 m (3300 ft) max. without derating.
Above 1000 m (3300 ft), derate 1% for every 100 m
(328 ft) up to a maximum altitude of 2000 m (6600 ft).
Maximum Surrounding Air Temperature without
derating:
IP20, Open Type:
IP30, NEMA Type 1, UL Type 1:
–10...50 °C (14...122 °F)
–10...45 °C (14...113 °F)
Cooling Method: Fan: All drive ratings
Storage Temperature:
2.2 kW (3.0 HP) to 7.5 kW (10 HP):
11 kW (15 HP) to 250 kW (350 (HP):
–40...85 °C (–40...185 °F)
–40...70 °C (–40...158 °F)
