124 Rockwell Automation Publication 22C-UM001J-EN-E - January 2017
Appendix A Supplemental Drive Information
Electrical
Atmosphere: Important: Drive must not be installed in an area where the
ambient atmosphere contains volatile or corrosive gas, vapors
or dust. If the drive is not going to be installed for a period of
time, it must be stored in an area where it will not be exposed
to a corrosive atmosphere.
Relative Humidity: 0...95% non-condensing
Shock (operating): 15G peak for 11 ms duration (±1.0 ms)
Vibration (operating): 1G peak, 5...2000 Hz
Seismic Rating: Meets the seismic requirements of the 2003 International
Building Code as specified by AC156.
(1)
(1) Drives 75 kW (100 HP) and greater have not been tested.
Specification
Voltage Tolerance: 200...240V ±10%
380...480V ±10%
Frequency Tolerance: 48...63 Hz
Input Phases: Three-phase input provides full rating.
Single-phase operation provides 35% rated current.
Displacement Power Factor: 0.98 across entire speed range
Efficiency: 97.5% at rated amps, nominal line voltage
Maximum Short Circuit Rating: 100,000 Amps Symmetrical (Frame C Drives)
200,000 Amps Symmetrical (Frame D–H Drives)
Actual Short Circuit Rating: Determined by AIC Rating of installed fuse/circuit breaker
Transistor Type: Isolated Gate Bipolar (IGBT)
Internal DC Bus Choke
200-480V AC Input:
380-480V AC Input:
11-37 kW (15-50 HP) Panel Mount Drives
11-160 kW (15-250 HP) Panel Mount Drives
Internal AC Line Reactor
380-480V AC Input: 200...250 kW (300...350 HP) Panel Mount Drives.
Specification
