Rockwell Automation Publication 22C-UM001J-EN-E - January 2017 69
Programming and Parameters Chapter 3
T061 [Relay Out2 Level] Related Parameter(s): T060
, T063, T064, d318
32 bit parameter.
Sets the trip point for the digital output relay if the value of T060 [Relay Out2 Sel] is 6, 7, 8, 9, 10 or 12
.
Values Default: 0.0
Min/Max: 0.0/9999
Display: 0.1
T060 Setting T061 Min/Max
6 0/320 Hz
70/180%
80/815 Volts
90/100%
10 1/180 degs
12 0/1
T063 [Relay 2 On Time] Related Parameter(s): T060, T061, T064
Sets delay time before Relay energizes after required condition testing.
Values Default: 0.0 Secs
Min/Max: 0.0/600.0 Secs
Display: 0.1 Secs
T064 [Relay 2 Off Time] Related Parameter(s): T060, T061, T063
Sets delay time before Relay de-energizes after required condition testing ceases.
Values Default: 0.0 Secs
Min/Max: 0.0/600.0 Secs
Display: 0.1 Secs
IMPORTANT
Do not use this parameter with Auxiliary Motor Control mode AutoSwap enabled.
