Rockwell Automation Publication 5069-UM004A-EN-P - April 2019 167

Configure a Standard Module Chapter 6

Edit 5069-IA16 Module

Configuration Categories

In addition to the General, Connection, and Module Info categories, the

Points category is available when you configure a 5069-IA16 module:

Points Category

The Points category shows the available input filter time values for the

module points.

For more information on input filters, see

page 84.

IMPORTANT If you use the Listen Only connection type, the Points category does

not appear.
