Rockwell Automation Publication 5069-UM004A-EN-P - April 2019 271
Module Tag Definitions Appendix B
Output Tags
Table 92 describes the 5069-OBV8S and 5069-OBV8SK module output tags.
Ptxx.Uncertain BOOL Indicates that the channel data can be inaccurate but the
degree of inaccuracy is not known.
For more information, see
Module Data Quality Reporting
on page 71.
• 0 = Good data
• 1 = Uncertain data
This tag is set to 1 when the module has
reached a critical operating temperature or is
higher the acceptable operating temperature.
IMPORTANT: Once the condition that causes
the tag to change to 1 is removed, the tag
automatically resets to 0.
Ptxx.ShortCircuit BOOL Indicates a short circuit • 0 = No short circuit
• 1 = Short circuit
Ptxx.FieldPowerOff BOOL Indicates that a field power loss condition exists on the
channel.
• 0 = No field power off condition
• 1 = Field power off condition
Ptxx.Status BOOL Indicates the channel status. • 0 = Bad, causing fault
• 1 = Good
(1) If the Point Mode for the test output is Pulse Test or Power Supply when the Short Circuit condition is detected, the condition can be corrected but you cannot set the test output to a safety state.
Table 91 - 5069-OBV8S and 5069-OBV8SK Module Input Tags
Name Data Type Definition Valid Values
Table 92 - 5069-OBV8S and 5069-OBV8SK Module Output Tags
Name Size Definition Valid Values
Ptxx.Data BOOL Indicates the current output value. • 0 = Off
• 1 = On
