Rockwell Automation Publication 5069-UM004A-EN-P - April 2019 179

Configure a Standard Module Chapter 6

Events Category

The Events category is available only if you choose Data with Events for

Connection in the Module Definition dialog box. Click the + sign next to the

Events category to expand it.

The Events subcategories show the configuration parameters for events.

IMPORTANT You cannot configure events on the Module Properties dialog box. The

parameters that are displayed are read-only.

You must use the Event Output tags to configure an event. For more

information, see

Configure an Event in the Event Output Tags on page 180.
