Rockwell Automation Publication 1609-UM009A-EN-P - January 2013 27
Bulletin 1609 UPS
Bul. 1609-D Specifications
1609-D600N 1609-D1000N 1609-D1500N
Input V nom. 120V 120V 120V
Capacity 600 VA (390 W) 1000 VA (650 W) 1500 VA (980 W)
Voltage Range, default 90...145V 90...145V 90...145V
Voltage Range, widest online 90...145V 90...145V 90...145V
Current nom. 5.5 A 8.8 A 13 A
Capacity Frequency 50/60 Hz ± 3 Hz 50/60 Hz ± 3 Hz 50/60 Hz ± 3 Hz
PFC None None None
Output V nom. 120V
Capacity 600 VA (390 W) 1000 VA (650 W) 1500 VA (980 W)
Online Output Voltage Range, default 108...132 V
Output Voltage Range, widest online 108...132 V
Transfer Point Accuracy ± 3 %
On Battery V nom 120V (sine wave)
Frequency 50/60 Hz ± 0.5Hz
THD ≤ 10% Full Linear Load
Short Circuit Protection Crest Factor 2.2:1
Efficiency On Battery (Typical with resistive load) 75%
Online - Typical with resistive load excluding AVR mode) 86% 94% 95%
Protection Surge 380 Joules
Overload (Shutdown after 10 s) > 110...130%
Overload (Shutdown immediately) 130%
Output Short Online/Battery Premises branch circuit over-current protection/Shutdown
Thermal Protection UPS inside temperature ≥ 60 ºC
Regulatory Safety UL1778, CSA C22.2 No. 107.3, EN/IEC62040-1
EMC FCC & CE (EN 62040-2)
Markings UL, cULus, FCC, CE, C-Tick
Battery Pack Run Time ≥5 min (at 25 °C, full R load) ≥3.5 min (25 °C, full R load) ≥2.5 min (at 25 °C, full R load)
Type Sealed Lead Acid Battery 12V/5Ah (for 0...40 °C B.B. BP5-12) 12V/5.5Ah (for 0...50 °CB.B. HRL5.5-12)
Voltage 36V
Charger Current limited, constant voltage float charger
Recharger Time Less than 8 hr to 90% capacity after discharge with full load
Lifetime 2...3 years at 25 °C ambient temperature
Environment Temperature Operating Standard Battery 0...+40 °C (+32...+104 °F) Hi-Temperature Battery 0...+50 °C (+32...+122 °F)
Non-operating/Storage -15...+45 °C (+5...+113 °F)
Altitude Operating 0...6600 feet (0... 2000 meters)
Humidity Operating/Storage 5...95% RH (Non-condensing)
Heat Output On Line, Full load: 217 BTU/hr
On Line, Full load, Charging:
296 BTU per hour
On Battery: Full Load: 1331 BTU
per hour
On Line, Full load: 142BTU/hr
On Line, Full load, Charging:
221 BTU per hour
On Battery: Full Load: 2218BTU
per hour
On Line, Full load: 176BTU/hr
On Line, Full load, Charging:
256BTU per hour
On Battery: Full Load: 3344BTU
per hour
Audible Noise < 50 dBA @ Front Side 1 Meter
Mechanical Approximate Dimensions L*W*H In. (mm)
8.66 x 16.14 x 10.24 (220 x 410 x 260)
Approximate Weight lbs (kg) 29.7 (13.5) 30.1 (13.7) 31 (14.1)
