Rockwell Automation Publication 1609-UM009A-EN-P - January 2013 29
Appendix A
1609 UPS Dimensions
1609-D UPS Dimensions
1609-B UPS Dimensions
1609-EXBAT Unit Dimensions
375
200
220
257
UNINTERRUPTIBLE
POWER SUPPLY
160 9-D
300
339
178
160
170
196
140
140
187
UNINTERRUPTIBLE
POWER SUPPLY
160 9-B
REMOTE FUNCTION 8 7 6 5 4 3 2 1
DISAB LE ENABLE
300
339
178
140140
196
160
170
187
197
