Bulletin 1609 UPS
Bul. 1609-B Specifications
1609-B600N 1609-B1000N
Input V nom. 120V 120V
Capacity 600 VA (360 W) 1000 VA (600 W)
Voltage Range, default 96...138V
Voltage Range, widest online 96...138V
Current nom. 5.4 A 8.9 A
Capacity Frequency 50/60 Hz ± 3 Hz 50/60 Hz ± 3 Hz
PFC None None
Output V nom. 120V
Capacity 600 VA (360 W) 1000 VA (600 W)
Online Output Voltage Range, default 96...138V
Output Voltage Range, widest online 96...138V
Transfer Point Accuracy ± 3%
On Battery V nom 120V (step wave)
Frequency 50/60 Hz ± 1 Hz
THD 47.5% (step wave) 47.6% (step wave)
Short Circuit Protection Crest Factor 2.5:1
Efficiency On Battery (Typical with resistive load) 80% Typical with resistive load
Online - Typical with resistive load excluding AVR mode) 94% Typical with resistive load
Protection Surge 380 Joules (Total performance rated with 10*1000 μ s pulse)
Overload (Shutdown after 10 s) > 110...130% - shutdown after 5 sec
Overload (Shutdown immediately) 130% shutdown immediately
Output Short: Online Premises branch circuit over-current protection
Output Short: Battery Shutdown
Thermal Protection UPS inside temperature ≥ 70 °C
Regulatory Safety UL1778, CSA C22.2 No. 107.3-05, EN/IEC62040-1
EMC FCC & CE (Class A)
Markings UL, cULus, FCC, CE, C-Tick
Battery Pack Run Time ≥5 min (at 25 °C, full load = 360W, PF = 0.6...0.75) ≥2 min (at 25 °C, full load = 600W, PF = 0.6...0.75)
Type Sealed Lead Acid Battery
12V/5Ah (for 0...40 °C: B.B. BP5...12)
12V/5.5 Ah (for 0...50 °C: B.B. HRL5.5...12)
Voltage 24V
Charger Current limited, constant voltage float charger
Recharger Time Less than 12 hrs to 90% capacity after discharge with full load
Lifetime 2...3 years at 25 °C ambient temperature
Environment Temperature Operating Standard Battery 0...+40 °C (+32...+104 °F) Hi-Temperature Battery 0...+50 °C (+32...+122 °F)
Non-operating/Storage -15...+45 °C (+5...+113 °F)
Altitude Operating 0...6600 feet (0... 2000 meters)
Humidity Operating/Storage 5...95% RH (Non-condensing)
Heat Output On Line, Full load: 107 BTU/hr
On Line, Full load, Charging: 160 BTU per hour
On Battery: Full Load: 1228 BTU per hour
On Line, Full load: 178 BTU/hr
On Line, Full load, Charging: 231 BTU per hour
On Battery: Full Load: 2047 BTU per hour
Audible Noise < 45 dBA @ Front Side 1 Meter
Mechanical Approximate Dimensions L*W*H In. (mm) 6.1 x 11 x 7.09 (155 x 300 x 180)
Approximate Weight lbs (kg) 14.5 (6.6) 14.7 (6.7)
