Allen-Bradley CompactLogix 5370 L1 User Manual

Rockwell Automation Publication 1769-UM021G-EN-P - October 2015 129
Communicate over Networks Chapter 6
Figure 9 - Example 1769-L27ERM-QBFC1B Control System Using DLR Network Topology
Figure 10 shows an example 1769-L33ERM control system using a DLR
network topology.
Figure 10 - Example 1769-L33ERM Control System Using a DLR Network Topology
1769-L27ERM-QBFC1B
PanelView Plus 7
Stratix 5700
PowerFlex 525
1734-AENTR POINT I/O
1794-AENTR FLEX™ I/O
Kinetix 5500
• 1769-AENTR
• 1769 Compact I/O
1769-L33ERM Control System
PanelView Plus 7
1794-AENTR FLEX I/O
Stratix 5700
1734-AENTR POINT I/O
Kinetix 5500
Kinetix 5500
• 1769-AENTR
• 1769 Compact I/O

Allen-Bradley CompactLogix 5370 L1 Specifications

General

Brand	Allen-Bradley
Model	CompactLogix 5370 L1
Category	Controller
Language	English
