Chapter 8 Use I/O Modules with CompactLogix 5370 L2 Controllers
34 S Ramp Rate Channel 0
35 Nu
36 EC Nu EHI ELI LC ER FM PM Nu PFE
37 Nu Outpt Fm ChI1 Nu Outpt Tp/RngeSel ChI1
38 S Fault Value Channel 1
39 S Program (Idle) Value Channel 1
40 S Clamp High Data Value Channel 1
41 S Clamp Low Data Value Channel 1
42 S Ramp Rate Channel 1
Where: EC Use to enable or disable a channel. Each channel can be individually enabled.
0 = Disable
1 = Enable
Inpt
Dta FM
CHIx
Use this bit to select the form in which the analog data is returned to the controller and used in the control program.
EA Use this bit to enable or disable the process alarms of a channel.
0 = Disable
1 = Enable
AL Use this bit to enable or disable alarm latching on the process alarm of a channel.
0 = No latch
1 = Latch
EI Use this bit to enable or disable interrupts on the process alarms of a channel.
0 = Disable
1 = Enable
EO Use this bit to enable or disable Open Circuit functionality on a channel.
0 = Disable
1 = Enable
Open
Circuit
Chx
Use to set the Open Circuit Response for a channel.
0 = Upscale
1 = Downscale
2 = Last State
3 = Zero
OV
adjust
CJC is performed by default by taking the CJC sensor temperature value for a given channel, converting that to a thermocouple voltage, and adding that
voltage from the measured value before converting to a user value. If this bit is set for a given channel, the signal value is directly converted to a user value
(No cold junction compensation performed).
Wire &
CLCD
Use to set the wire mode. The combination of values in bits 14 and 15 determine the mode, as listed in the following table.
TU Chx Use to set the temperature units.
0 = Degrees Celsius
1 = Degrees Fahrenheit
Table 18 - CompactLogix 5370 L2 Controller Embedded Analog I/O Module Configuration Image Array
Word Bit
1514131211109876543210
Bit 15 Value Bit 14 Value Mode
0 0 3-wire and cycle lead compensation - Enable
0 1 3-wire and cycle lead compensation - Disable
1 0 2-wire (No lead compensation)
1 1 4-wire (No lead compensation)
