Rockwell Automation Publication 1756-UM001M-EN-P - February 2012 67
Start Using the Controller Chapter 3
Table 7 - Load Image Options
The table below describes the Load Mode options you can choose for the
project.
Table 8 - Load Mode Options
The table below describes the Automatic Firmware Update options you
can choose for the project. The Automatic Firmware Update property is
also referred to as the Firmware Supervisor feature.
If you want the image (project) to load when Then choose
Power to the controller is applied or cycled On Power Up
The controller has lost the project and power has been cycled
or applied
On Corrupt Memory
Initiated by using RSLogix 5000 software User Initiated
If you want the controller to go to this mode after
loading
Then choose
Program Program (Remote Only)
Run Run (Remote Only)
