Rockwell Automation Publication 1756-UM001M-EN-P - February 2012 69
Start Using the Controller Chapter 3
After clicking Store, the project is saved to the memory card as indicated by
the controller status indicators.
Table 10 - Store Project Status Indicators
With these controllers These indications show the store status
1756-L6x While the store is in progress, the following occurs:
• OK indicator on the controller is solid red
• A dialog box in RSLogix 5000 software indicates the store is in progress
When the store is complete, the following occurs:
• OK indicator on the controller is momentarily red, then solid green
• CF indicator on the controller is off
1756-L7x While the store is in progress, the following occurs:
• OK indicator is flashing green
• SD indicator is flashing green
• SAVE is shown on the status display
• A dialog box in RSLogix 5000 software indicates the store is in progress
When the store is complete, the following occurs:
• OK indicator on the controller is solid green
• SD indicator on the controller is off
Allow the store to complete without interruption. If you interrupt the store,
data corruption or loss may occur.
