1785-UM022B-EN-P - February 2002
Appendix
F
ControlNet Diagnostics File Layout
When you specify a Control Diagnostic File in RSNetWorx for the
ControlNet network, the PLC-520C, -5/40C, -5/46C or -5/80C
processor copies the 40 words of diagnostic counters into the
specified integer file.
Twenty-three additional diagnostic counters are available in the
ControlNet diagnostic file. To access these counters, you must first
use RSLogix5 to increase the size of the ControlNet diagnostic
integer file to 63 words.
The layout of the ControlNet diagnostic file is described in the
following table. The processor updates this file once every second.
Field Names
File Offset
1
(word;bits)
Buffer Errors 0;15-00
Last 8 Nodes from which bad packets were received 1-4;
Good Frames Transmitted (center significant byte) 5;07-00
Good Frames Transmitted (least significant byte) 5;15-08
Good Frames Received (least significant byte) 6;07-00
Good Frames Transmitted (most significant byte) 6;15-08
Good Frames Received (most significant byte) 7;07-00
Good Frames Received (center significant byte) 7;15-08
Channel A Errors 8;07-00
Bad Received Frames 8;15-08
Aborted Frames Transmitted 9;07-00
Channel B Errors 9;15-08
NUI Overloads 10;07-00
Highwaters/Out-of-Steps 10;15-08
Blockages 11;07-00
Slot Overloads 11;15-08
Aborted Frames Received 12;07-00
Non-Concurrences 12;15-08
Frames with Duplicate Node Address Received 13;07-00
Lonely Occurrences 13;15-08
Collisions 14;07-00
Noise Hits 14;15-08
Moderators from non-lowmen 15;07-00
