1785-UM022B-EN-P - February 2002
F-2 ControlNet Diagnostics File Layout
Node Address of current Moderator 15;15-08
Cannot Hear Moderator Occurrences (i.e., Lonely) 16;07-00
Network Parameter Mismatch Occurrences 16;15-08
Reserved 17;07-00
SM Commands Received from the wire 17;15-08
Reserved 18;07-00
Reserved 18;15-08
Fault Register -- Pre Reset 19;07-00
Reserved 19;15-08
Reserved 20;07-00
Fault Register -- Post Reset 20;15-08
Dirty bits 21;7-0
SMAC version number 21;15-8
Interface mode 22;7-0
Toggle bits 22;15-8
Channel status (see following table) 23;7-0
Media bits (see following table) 23;15-8
Keeper State 24
Reserved 25-39
Current number of open scheduled connections
(always less than or equal to the number in Word 41)
40
Current number of configured scheduled connections 41
Accumulated number of scheduled connection timeouts 42
Current number of active MSG instructions
(always less than or equal to 32)
43
Maximum number of simultaneously active MSG instructions
(always less than or equal to 32)
44
Accumulated number of MSG connection timeouts 45
Current number of active 1771 CIO instructions
(always less than or equal to 32)
46
Maximum number of simultaneously active 1771 CIO
instructions (always less than or equal to 32)
47
Accumulated number of 1771 CIO connection timeouts 48
Current number of active 1794 and CIP CIO instructions
(always less than or equal to 8)
49
Maximum number of simultaneously active 1794 and CIP CIO
instructions (always less than or equal to 8)
50
Accumulated number of 1794 and CIP CIO connection timeouts 51
Current number of open target Message Router connections
(always less than or equal to 32)
52
Field Names
File Offset
1
(word;bits)
