Kinetix 5700 DC-bus Power Supplies 15
Rockwell Automation Publication 2198-IN009B-EN-P - June 2015
Specifications
Additional Resources
These documents contain additional information concerning related products from Rockwell
Automation.
You can view or download publications at http://www.rockwellautomation.com/literature. To
order paper copies of technical documentation, contact your local Allen-Bradley distributor or
Rockwell Automation sales representative.
Attribute 2198-P031 2198-P070 2198-P141 2198-P208
Surrounding air temperature
Operating
Storage
0…50 °C (32…122 °F)
-40…70 °C (-40…158 °F)
Weight, kg (lb) approx 4.33 (9.55) 4.42 (9.74) 6.91 (15.2) 7.04 (15.5)
Short-circuit current rating 200,000 A rms symmetrical
Branch-circuit short-circuit
protection
Integral solid-state short circuit protection does not provide branch circuit protection. Branch
circuit protection must be provided in accordance with the Nation al Electric Code (NEC) and any
additional local codes.
Leakage
current
• Kinetix 5700 drives produce leakage current in the protective-earthing conductor that exceeds 3.5 mA AC
and/or 10 mA DC. The minimum size of the protective-earthing (grounding) conductor used in the application
must comply with local safety regulations for high-protective-earthing conductor current equipment.
• Kinetix 5700 drives produce DC current in the protective-earthing conductor and can reduce the ability of a
residual current device (RCD) or residual current monitor (RCM) of type A or AC to provide protection for the
drive module and other equipment in the installation.
Resource Description
Kinetix 5700 Servo Drives User Manual, publication 2198-UM002
Information on installing, configuring, starting, and
troubleshooting your Kinetix 5700 servo drive system.
Kinetix 5000 AC Line Filter Installation Instructions,
publication 2198-IN003
Information on installing and wiring the Kinetix 5500 and
Kinetix 5700 AC line filters.
Kinetix 5700 Passive Shunt Modules Installation Instructions,
publication 2198-IN011
Information on installing and wiring Kinetix 5700 external
shunt modules.
Kinetix Servo Drives Specifications Technical Data,
publication GMC-TD003
Provides product specifications for the Kinetix Integrated
Motion over EtherNet/IP network, Integrated Motion over
sercos interface, EtherNet/IP networking, and component
servo drive families.
Kinetix Motion Accessories Specifications Technical Data,
publication GMC-TD004
Provides product specifications for Bulletin 2090 motor and
interface cables, low-profile connector kits, drive power
components, and other servo drive accessory items.
Industrial Automation Wiring and Grounding Guidelines,
publication 1770-4.1
Provides general guidelines for installing a Rockwell
Automation® industrial system.
Product Certifications website, http://www.ab.com
Provides declarations of conformity, certificates, and other
certification details.
