108 Rockwell Automation Publication KNX-RM003B-EN-P - March 2019
Kinetix 6000 and Kinetix 6200/6500 Drive Systems
Kinetix 6000 (200V-class) Drives with LDL-Series Linear Motors
This section provides system combination information for the Kinetix 6000 (200V-class) drives when matched with
LDL-Series™ ironless linear motors. Included are power and feedback cable catalog numbers, system performance
specifications, and the optimum force/velocity curves.
LDL-Series Cable Combinations
For cable configuration illustrations and feature descriptions, by catalog number, see 2090-Series Motor/Actuator Cables Overview beginning on page 8.
Motor-end connector kits, and panel-mounted breakout components (drive end), are available for motor power/brake and feedback cables. See Optional Drive Accessories on page 6
.
Cable length xx is in meters. See the Kinetix Motion Accessories Technical Data, publication KNX-TD004
, for standard cable lengths.
LDL-Series Performance Specifications with Kinetix 6000 (200V-class) Drives
Performance specification data and curves reflect nominal system performance of a typical system with actuator at 40 °C (104 °F) and drive at 50 °C (122 °F) ambient and rated line voltage. For additional
information on ambient and line conditions, see Motion Analyzer software.
Linear Motors Motor Power Cable Motor Feedback Cable
(1)
(1) Use low-profile connector kit (catalog number 2090-K6CK-D15M) on the drive end. See Required Drive Accessories on page 4.
LDL-N030120-DHT, LDL-N030240-DHT, LDL-N030240-EHT
2090-CPWM7DF-16AAxx (standard, non-flex)
2090-CPWM7DF-16AFxx (continuous-flex)
2090-XXNFMF-Sxx (standard, non-flex)
2090-CFBM7DF-CDAFxx (continuous-flex)
Sin/Cos or TTL Encoder Feedback
LDL-N050120-DHT, LDL-N050240-DHT, LDL-N050240-EHT,
LDL-N050360-DHT, LDL-N050360-EHT, LDL-N050480-DHT, LDL-N050480-EHT
LDL-N075480-DHT, LDL-N075480-EHT
LDL-T030120-DHT, LDL-T030240-DHT, LDL-T030240-EHT
LDL-T050120-DHT, LDL-T050240-DHT, LDL-T050240-EHT,
LDL-T050360-DHT, LDL-T050480-DHT, LDL-T050480-EHT
LDL-T075480-DHT, LDL-T075480-EHT
Linear Motor
Cat. No.
Speed, max
m/s (ft/s)
System Continuous
Stall Current
Amps 0-pk
System Continuous
Stall Force
N (lb)
System Peak Stall
Current
Amps 0-pk
System Peak Stall
Force
N (lb)
Linear Motor
Rated Output
kW
Kinetix 6000
200V-class Drives
LDL-N030120-DHT
10.0 (32.8)
3.0 63 (14) 9.9 209 (47) 0.31 2094-AMP5-S
LDL-N030240-DHT 6.0
126 (28)
19.9
417 (94) 0.63
2094-AM01-S
LDL-N030240-EHT 3.0 9.9 2094-AMP5-S
LDL-T030120-DHT 3.0 72 (16) 9.9 239 (54) 0.36 2094-AMP5-S
LDL-T030240-DHT 6.0
144 (32)
19.9
479 (108) 0.72
2094-AM01-S
LDL-T030240-EHT 3.0 9.9 2094-AMP5-S
