Kinetix 6000 and Kinetix 6200/6500 Drive Systems
Bulletin MPL Motor Performance Specifications with Kinetix 6200/6500 (400V-class) Drives
Rotary Motor
Cat. No.
Rated Speed
rpm
Speed, max
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 6200/
Kinetix 6500
400V-class Drives
MPL-B1510V 8000 8000 0.95 0.26 (2.3) 3.10 0.77 (6.8) 0.16 2094-BMP5-M
MPL-B1520U 7000 7000 1.80 0.49 (4.3) 6.10 1.58 (13.9) 0.27 2094-BMP5-M
MPL-B1530U 7000 7000 2.0 0.90 (8.0) 7.20 2.82 (24.9) 0.39 2094-BMP5-M
MPL-B210V 8000 8000 1.75 0.55 (4.9) 5.80 1.52 (13.4)
0.37 2094-BMP5-M
MPL-B220T 6000 6000 3.30 1.61 (14.2)
9.90 4.12 (36.4)
0.62
2094-BMP5-M
11.3 4.74 (41.9) 2094-BM01-M
MPL-B230P 5000 5000 2.60 2.10 (18.6)
9.90 7.24 (64.0)
0.86
2094-BMP5-M
11.3 8.20 (73.0) 2094-BM01-M
MPL-B310P 5000 5000 2.4 1.6 (14.1) 7.10 3.6 (32) 0.77 2094-BMP5-M
MPL-B320P 5000 5000
4.0 2.7 (23.9) 9.90 5.9 (52.2)
1.5
2094-BMP5-M
4.5 3.10 (27) 14.0 8.2 (72.5) 2094-BM01-M
MPL-B330P 5000 5000
4.0 2.7 (23.9) 9.90 6.8 (60.2)
1.8
2094-BMP5-M
6.1 4.18 (37) 19.0 11.1 (98) 2094-BM01-M
MPL-B420P 5000 5000 6.3 4.74 (42)
21.6 13.1 (116)
1.9
2094-BM01-M
22.0 13.5 (119) 2094-BM02-M
MPL-B430P 5000 5000
8.6 6.2 (54.9) 21.6 13.9 (123)
2.2
2094-BM01-M
9.2 6.55 (58) 32.0 19.8 (175) 2094-BM02-M
MPL-B4530F 3000 3000
4.0 4.9 (43.3) 9.90 11.0 (97.3)
2.1
2094-BMP5-M
6.7 8.36 (74) 21.0 20.3 (180) 2094-BM01-M
MPL-B4530K 4000 4000
8.6 7.1 (62.8) 21.6 15.1 (133)
2.6
2094-BM01-M
9.9 8.25 (73) 31.0 20.3 (179) 2094-BM02-M
MPL-B4540F 3000 3000
8.6 9.5 (84.1) 21.6 20.9 (185)
2.6
2094-BM01-M
9.1 10.20 (90) 29.0 27.1 (240) 2094-BM02-M
MPL-B4560F 3000 3000
8.6 10.5 (92.9) 21.6 22.7 (201)
3.2
2094-BM01-M
11.8 14.0 (124) 36.0 34.4 (304) 2094-BM02-M
MPL-B520K 3500 4000
8.6 7.9 (69.9) 21.6 16.6 (147)
3.5
2094-BM01-M
11.5 10.7 (95) 33.0 23.2 (205) 2094-BM02-M
MPL-B540D 2000 2000
8.6 15.8 (139) 21.6 37.9 (335)
3.4
2094-BM01-M
10.5 19.4 (172) 23.0 41.0 (362) 2094-BM02-M
MPL-B540K 4000 4000 20.4 19.4 (171) 60.0 48.6 (430) 5.4 2094-BM03-M
MPL-B560F 3000 3000 20.6 26.8 (237) 68.0 67.8 (600) 5.5 2094-BM03-M
MPL-B580F 3000 3000 26.0 34.0 (300)
75.0 74.6 (660)
7.1
2094-BM03-M
94.0 87.0 (770) 2094-BM05-M
MPL-B580J 3800 3800
30.0 31.7 (280) 75.0 67.0 (592)
7.9
2094-BM03-M
32.0 34.0 (301) 94.0 81.0 (716) 2094-BM05-M
MPL-B640F 2000 3000
30.0 34.4 (304)
65.0 72.3 (640) 6.1
2094-BM03-M
32.0 36.7 (325) 2094-BM05-M
MPL-B660F 2000 3000 38.5 48.0 (425) 96.0 101 (895) 6.1 2094-BM05-M
MPL-B680D 2000 2000
30.0 55.4 (490) 75.0 125 (1105)
9.3
2094-BM03-M
34.0 62.8 (556) 94.0 154 (1365) 2094-BM05-M
