32 Rockwell Automation Publication KNX-RM003B-EN-P - March 2019
Kinetix 6000 and Kinetix 6200/6500 Drive Systems
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 50 °C (122 °F) ambient and rated line voltage. For additional
information on ambient and line conditions, see Motion Analyzer software.
MPM-B1653C 1500 2000 2500 20.05 26.7 (236)
45.0 55.0 (487)
4.60
2094-BM03-S @ 150%
59.2 67.7 (599) 2094-BM03-S @ 250%
MPM-B1653E 2250 3000 3500 27.00 26.8 (237)
45.0 42.5 (376)
5.10
2094-BM03-S @ 150%
72.9 62.0 (549) 2094-BM03-S @ 250%
MPM-B1653F 3000 3000 4000 34.94 31.0 (274)
73.4 47.8 (423)
5.10
2094-BM05-S @ 150%
94.3 56.0 (495) 2094-BM05-S @ 200%
MPM-B2152C 1500 2000 2500 27.4 36.7 (325)
45.0 60.3 (534)
5.60
2094-BM03-S @ 150%
55.4 72.2 (639) 2094-BM03-S @ 250%
MPM-B2152F 3000 2500 4500 43.54 34.1 (302)
73.4 56.2 (497)
5.90
2094-BM05-S @ 150%
97.8 72.3 (495) 2094-BM05-S @ 200%
MPM-B2152M 4500 2500 5000 44.58 34.1 (302)
73.4 51.0 (451)
5.90
2094-BM05-S @ 150%
76.3 52.9 (468) 2094-BM05-S @ 200%
MPM-B2153B 1250 1750 2000 24.06 48.0 (425)
45.0 80.0 (708)
6.80
2094-BM03-S @ 150%
60.0 101 (894) 2094-BM03-S @ 250%
MPM-B2153E 2250 2000 3000 39.63 47.9 (424)
73.4 79.4 (703)
7.20
2094-BM05-S @ 150%
97.8 101 (894) 2094-BM05-S @ 200%
MPM-B2153F 3000 2000 3800 43.86 45.6 (403)
73.4 75.0 (664)
7.20
2094-BM05-S @ 150%
97.8 99.0 (875) 2094-BM05-S @ 200%
MPM-B2154B 1250 1750 2000 35.46 62.7 (555)
73.4 121 (1071)
6.90
2094-BM05-S @ 150%
97.8 154 (1362) 2094-BM05-S @ 200%
MPM-B2154E 2250 2000 3000 43.68 55.9 (495)
73.4 87.7 (776)
7.50
2094-BM05-S @ 150%
97.8 112 (990) 2094-BM05-S @ 200%
MPM-B2154F 3000 2000 3300 44.40 56.2 (497)
73.4 78.8 (697)
7.50
2094-BM05-S @ 150%
83.6 88.0 (778) 2094-BM05-S @ 200%
Bulletin MPM Motor Performance Specifications with Kinetix 6000 (400V-class) Drives (continued)
Rotary Motor
Cat. No.
Base Speed
rpm
Rated Speed
rpm
Speed, max
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 6000
400V-class Drives
To Next Page
