Rockwell Automation Publication MOTION-UM003K-EN-P - January 2019 181
Configuration Examples for a Kinetix Drive Chapter 8
3. From the Data Source pull-down menu, choose a data source.
In this case, the data source is Catalog Number and the Motion
Database provides values for these fields.
See the Display Motor Model Information on page 54
for more
information about data sources.
Figure 48 - Example 6: Frequency Control with No Feedback, Motor Dialog Box
4. From the Frequency Control Method pull-down menu, choose the
appropriate method.
This example uses Basic Volts/Hertz.
5. Click Apply.
Figure 49 - Example 5: Frequency Control with No Feedback, Frequency Control Dialog Box
