Rockwell Automation Publication MOTION-UM003K-EN-P - January 2019 213
Axis Configuration Examples for the PowerFlex 527 Drive Chapter 10
19. Select the Actions category.
The Actions to Take Upon Conditions dialog box appears.
Figure 91 - Example 1: Frequency Control with No Feedback, Actions to Take Upon Conditions
Dialog Box
From this dialog box, you can program actions and change the action for
exceptions (faults). See the PowerFlex 527 Adjustable Frequency AC
Drive User Manual, publication 520-UM002
for more information.
Some out-of-box settings must be applied here. See Appendix C
,
PowerFlex® 527 Out-of-Box Configuration on page 339
for more
information.
20. Select the Parameter List category.
The Motion Axis Parameters dialog box appears.
Figure 92 - Example 1: Frequency Control with No Feedback, Motion Axis Parameters Dialog
Box
From this dialog box, you can program actions and change the action for
exceptions (faults). See the PowerFlex 527 Adjustable Frequency AC
Drive User Manual, publication 520-UM002
for more information.
