76 Rockwell Automation Publication MOTION-UM003K-EN-P - January 2019

Chapter 4 Configure Integrated Motion Control Using Kinetix 5700 Drives

The Safety Network Number (SNN) field populates automatically

when the Connection mode includes an integrated Motion and Safety

or Safety-only connection. For a detailed explanation of the safety

network number, refer to the appropriate GuardLogix controller

publication as defined in Additional Resources on page 9

5. To close the Module Definition dialog box, click OK.

6. Click Apply.

Configure the Power and Safety Options

1. Click the Power category.

IMPORTANT The Logix Designer application enforces shared-bus configuration rules for

Kinetix 5700 drives.
