Kinetix 7000 High Power Servo Drives 3
Rockwell Automation Publication 2099-IN003C-EN-P - June 2015
Catalog Number Explanation
This publication applies to the following Kinetix 7000 servo drives.
Kinetix 7000 Drive Catalog Numbers
Before You Begin
Remove all packing material, wedges, and braces from within and around the components. After
unpacking, check the item nameplate catalog number against the purchase order.
Parts List
The Kinetix 7000 servo drives ship with the following:
• General purpose I/O (GPIO) wiring header, general purpose relay (GPR) header,
control power (CP), safe-off (SO) wiring plug header with a motion-allowed jumper
• Ground clamp and strain relief for motor power cable
• These installation instructions, publication 2099-IN003
Drive Cat. No. Input Voltage
Continuous Output Power
Continuous
Output Current
kW Hp A 0-pk
2099-BM06-S
342…528V AC rms
Three-phase
22 30 56
2099-BM07-S 304073
2099-BM08-S 375092
2099-BM09-S 56 75 135
2099-BM10-S 75 100 176
2099-BM11-S 112 150 254
2099-BM12-S 149 200 351
Connector kits for user I/O, auxiliary feedback, and motor feedback are not provided.
Replacement connector sets, as described in the Parts List, are available. Refer to the Kinetix
Motion Accessories Technical Data, publication GMC-TD004
, for more information on
connector kits and replacement connector sets.
