Publication 1756-PM004C-EN-P - October 2009 43
Organize Tags Chapter 2
RSLogix 5000 software uses different colors for descriptions.
Activate Pass-Through and Append Descriptions
Follow these steps to use pass-through descriptions and append to
base tag descriptions.
1. In the RSLogix 5000 programming software, from the Tools menu
choose Options.
The Work Station Options screen appears.
2. Under Application, select Display.
3. Check Show Pass-Through Descriptions and Append to Base Tag
Descriptions.
4. Click OK.
Color Descriptions
If Color Description Is This Is
Gray Pass-through description
Black Manually entered description
