310 Rockwell Automation Publication 2080-UM002K-EN-E - March 2019
Appendix E Troubleshooting
0xF0Az
(3)
Recoverable The plug-in I/O module experienced an error
during operation.
Perform the following:
• Check the condition and operation of the plug-in I/O module.
• See Corrective Actions for Recoverable Faults
on page 313.
0xF0Bz
(3)
Recoverable The plug-in I/O module configuration does not
match the actual I/O configuration detected.
Perform one of the following:
• See Corrective Actions for Recoverable Faults on page 313.
• Correct the plug-in I/O module configuration in the user program to
match that of the actual hardware configuration.
• Check the condition and operation of the plug-in I/O module.
• Replace the plug-in I/O module.
0xF0Dz
(3)
Recoverable When power was applied to the plug-in I/O
module or the plug-in I/O module was removed, a
hardware error occurred.
Perform the following:
1. See Corrective Actions for Recoverable Faults on page 313.
2. Correct the plug-in I/O module configuration in the user program.
3. Build and download the program using Connected Components
Workbench.
4. Put the Micro800 controller into Run mode.
0xF0Ez
(3)
Recoverable The plug-in I/O module configuration does not
match the actual I/O configuration detected.
Perform the following:
1. See Corrective Actions for Recoverable Faults on page 313.
2. Correct the plug-in I/O module configuration in the user program.
3. Build and download the program using Connected Components
Workbench.
4. Put the Micro800 controller into Run mode.
0xF830 Recoverable An error occurred in the EII configuration. Perform the following:
• See Corrective Actions for Recoverable Faults on page 313.
• Review and change the EII configuration in the Micro800 controller
properties.
0xF840 Recoverable An error occurred in the HSC configuration. Perform the following:
• See Corrective Actions for Recoverable Faults
on page 313.
• Review and change the EII configuration in the Micro800 controller
properties.
0xF850 Recoverable An error occurred in the STI configuration. Perform the following:
• See Corrective Actions for Recoverable Faults
on page 313.
• Review and change the EII configuration in the Micro800 controller
properties.
0xF860 Recoverable A data overflow occurred.
A data overflow error is generated when the
ladder, structured text or function block diagram
execution encounters a divide-by-zero.
Perform the following:
1. See Corrective Actions for Recoverable Faults on page 313.
2. Correct the program to ensure that there is no data overflow.
3. Build and download the program using Connected Components
Workbench.
4. Put the Micro800 controller into Run mode.
0xF870 Recoverable An index address was out of data space. Perform the following:
1. See Corrective Actions for Recoverable Faults
on page 313.
2. Correct the program to ensure that there is no index used to access
an array element beyond the array boundaries.
3. Build and download the program using Connected Components
Workbench.
4. Put the Micro800 controller into Run mode.
List of Error Codes for Micro800 controllers
Error Code Fault Type Description Recommended Action
