Rockwell Automation Publication 1763-UM002E-EN-P - October 2015 5
Chapter 2
Use Data Views to Access Controller Data
How to Use This Chapter
The MicroLogix 1100 controllers provide access to the controller data table files.
This chapter shows you how to set up data views of data table files.
Overview of Data Views
Data views give you the ability to read from controller through a browser
interface. The MicroLogix 1100 controller provides web pages that let you
configure a set of files (a data view) that can be read.
A data view consists of an HTML file with data file information. The HTML file
is in a readable ASCII format. It contains the File Name, File Type, # of Element,
and Access Group.
Topic
Page
Overview of Data Views
5
Change an Access Group
6
Monitor Data Views and Data Table File
7
Change Data Table Files
7
Disable Web View
9

Allen-Bradley MicroLogix 1100 Specifications

General

Processor	32-bit
Programming Software	RSLogix 500
Mounting	DIN rail or panel mount
Power Supply	24V DC
Type	Compact PLC
Digital Inputs	12
Digital Outputs	8
Analog Inputs	4 (depending on model)
Analog Outputs	Optional with expansion module
Programming Language	Ladder Logic
Operating Temperature	0 to 55 °C (32 to 131 °F)
Series	MicroLogix
