Rockwell Automation Publication 1763-UM002E-EN-P - October 2015 1
Chapter 1
MicroLogix 1100 Embedded Web Server
How to Use This Chapter
Rockwell Automation offers enhanced MicroLogix 1100 controllers for your
EtherNet/IP control systems so you can monitor data remotely via web pages.
This chapter shows how you can use a MicroLogix 1100 controller in your
control system.
Typical Applications
The MicroLogix 1100 controller provides access to controller data. This access
opens up different, remote access applications to control systems. Use the
MicroLogix 1100 controller to remotely access controller data using a web
browser. Use a web browser to monitor live controller data.
Browser Requirements
You can access the MicroLogix 1100 Web Server only with Internet Explorer 6, 7,
or 8. Internet Explorer 9 or above are not supported because of JavaScript
incompatibility.
To access data view pages, the browser requires Javascript support.
The supported display size is 640 x 480 or greater. Smaller display sizes work but
might require extensive scrolling to view the information.
Topic
Page
Typical Applications
1
Browser Requirements
1
Connect the MicroLogix 1100 controller to the Network
2
Navigate the MicroLogix 1100 Controller
4

Allen-Bradley MicroLogix 1100 Specifications

General

Processor	32-bit
Programming Software	RSLogix 500
Mounting	DIN rail or panel mount
Power Supply	24V DC
Type	Compact PLC
Digital Inputs	12
Digital Outputs	8
Analog Inputs	4 (depending on model)
Analog Outputs	Optional with expansion module
Programming Language	Ladder Logic
Operating Temperature	0 to 55 °C (32 to 131 °F)
Series	MicroLogix
