Allen-Bradley MicroLogix 1200 Reference Manual

Publication 1762-RM001C-EN-P
1-2 I/O Configuration
AC embedded inputs have fixed input filters. DC embedded inputs have
configurable input filters for a number of special functions that can be
used in your application. These are: high-speed counting, event
interrupts, and latching inputs. The 1764-28BXB has two high-speed
outputs for use as pulse train output (PTO) and/or pulse width
modulation (PWM) outputs. The 1762-L24BXB and -L40BXB each have
one high-speed output.

Allen-Bradley MicroLogix 1200 Specifications

General

Series	MicroLogix 1200
Type	Programmable Logic Controller (PLC)
Mounting	DIN rail or panel mount
Programming Language	Ladder Logic
Programming Software	RSLogix 500
I/O Points	Up to 40
Communication Ports	RS-232, RS-485
Memory	6 KB user memory
Power Supply	24V DC or 120/240V AC
Expansion	Supports expansion I/O modules
Operating Temperature	0°C to 55°C (32°F to 131°F)
Dimensions	90 mm x 110 mm
Weight	0.5 kg (1.1 lbs)
