Allen-Bradley MicroLogix 1200 Reference Manual

Publication 1762-RM001C-EN-P
1-18 I/O Configuration
Configuring Expansion
I/O Using RSLogix 500
Expansion I/O must be configured for use with the controller. Configuring
expansion I/O can be done either manually, or automatically. Using
RSLogix 500:
1. Open the “Controller” folder.
2. Open the “I/O Configuration” folder.
3. For manual configuration, drag the Compact I/O module to the slot.
For automatic configuration, you must have the controller connected
to the computer (either directly or over a network). Click the “Read
I/O Config” button on the I/O configuration screen. RSLogix 500 will
read the existing configuration of the controller’s I/O.
Some I/O modules support or require configuration. To configure a
specific module, double-click on the module, an I/O configuration screen
will open that is specific to the module.

Allen-Bradley MicroLogix 1200 Specifications

General

Series	MicroLogix 1200
Type	Programmable Logic Controller (PLC)
Mounting	DIN rail or panel mount
Programming Language	Ladder Logic
Programming Software	RSLogix 500
I/O Points	Up to 40
Communication Ports	RS-232, RS-485
Memory	6 KB user memory
Power Supply	24V DC or 120/240V AC
Expansion	Supports expansion I/O modules
Operating Temperature	0°C to 55°C (32°F to 131°F)
Dimensions	90 mm x 110 mm
Weight	0.5 kg (1.1 lbs)
