Allen-Bradley MicroLogix 1200 Reference Manual

Publication 1762-RM001C-EN-P
Using Interrupts 18-21
EII Edge Select (ES)
The ES (Edge Select) bit selects the type of trigger that causes an Event
Interrupt. This bit allows the EII to be configured for rising edge
(off-to-on, 0-to-1) or falling edge (on-to-off, 1-to-0) signal detection. This
selection is based on the type of field device that is connected to the
controller.
The default condition is 1, which configures the EII for rising edge
operation.
EII Input Select (IS)
The IS (Input Select) parameter is used to configure each EII to a specific
input on the controller. Valid inputs are 0 to 7, which correspond to
I1:0.0/0 to I1:0.0/7.
This parameter is configured with the programming device and cannot be
changed from the control program.
Sub-Element Description Address Data Format Type User Program
Access
ES - Edge Select EII:0/ES binary (bit) control read only
Sub-Element Description Address Data Format Type User Program
Access
IS - Input Select EII:0.IS word (INT) control read only

Allen-Bradley MicroLogix 1200 Specifications

General

Series	MicroLogix 1200
Type	Programmable Logic Controller (PLC)
Mounting	DIN rail or panel mount
Programming Language	Ladder Logic
Programming Software	RSLogix 500
I/O Points	Up to 40
Communication Ports	RS-232, RS-485
Memory	6 KB user memory
Power Supply	24V DC or 120/240V AC
Expansion	Supports expansion I/O modules
Operating Temperature	0°C to 55°C (32°F to 131°F)
Dimensions	90 mm x 110 mm
Weight	0.5 kg (1.1 lbs)
