Allen-Bradley PanelView Plus 1000 User Manual

Publication 2711P-UM001A-EN-P
Overview 1-9
Legend Kits
Protective Antiglare Overlays
Backlights
Miscellaneous
Cat. No. Description
2711P-RFK7 Replacement Legend Strips for 700 Keypad Terminal
2711P-RFK10 Replacement Legend Strips for 1000 Keypad Terminal
2711P-RFK12 Replacement Legend Strips for 1250 Keypad Terminal
2711P-RFK15 Replacement Legend Strips for 1500 Keypad Terminal
Cat. No. Description
2711P-RGK7 Antiglare Overlay for PanelView Plus 700 Keypad or Keypad/Touch Terminal
2711P-RGT7 Antiglare Overlay for PanelView Plus 700 Touch Terminal
2711P-RGK10 Antiglare Overlay for PanelView Plus 1000 Keypad or Keypad/Touch
Terminal
2711P-RFT10 Antiglare Overlay for PanelView Plus 1000 Touch Terminal
2711-RFK12 Antiglare Overlay for PanelView Plus 1250 Keypad or Keypad/Touch
Terminal
2711-RFT12 Antiglare Overlay for PanelView Plus 1250 Touch Terminal
2711-RFK15 Antiglare Overlay for PanelView Plus 1500 Keypad or Keypad/Touch
Terminal
2711-RFT15 Antiglare Overlay for PanelView Plus 1500 Touch Terminal
Cat. No. Description
2711P-RL7C Replacement Color Backlight for PanelView Plus 700 Terminals
2711P-RL10C Replacement Color Backlight for PanelView Plus 1000 Terminals
2711P-RL12C Replacement Color Backlight for PanelView Plus 1250 Terminals
Cat. No. Description
2711P-RY2032 Replacement Battery
2711P-RTMC Mounting Clips
6189-2CONN DC, AC and 6182 Relay Connectors
AB PLCs

Allen-Bradley PanelView Plus 1000 Specifications

General

Display Size	10.4 inches
Resolution	640 x 480 pixels
Touchscreen	Analog resistive
Operating System	Windows CE
Memory	64 MB RAM
Storage	64 MB Flash
Communication Ports	Ethernet, RS-232, USB
Input Voltage	24V DC
Display Type	Color TFT
Processor	XScale
Enclosure	NEMA 4X
Operating Temperature	0°C to 50°C
