Page #20 background image
Publication 2711P-UM001A-EN-P
1-10 Overview
Adapter Plates
Cables
Communication Adapters
Cat. No. Description
2711P-RAK7 Adapts a PanelView Plus 700 Keypad Terminal to a PanelView
Standard 900 Keypad Cutout
2711P-RAT7 Adapts a PanelView Plus 700 Touch Terminal to a PanelView
Standard 900 Touch Cutout
2711P-RAK10 Adapts a PanelView Plus 1000 Keypad Terminal to a PanelView
1000/1000E Keypad Cutout
2711P-RAT10 Adapts a PanelView Plus 1000 Touch Terminal to a PanelView
1000/1000E Touch Cutout
2711P-RAK12E Adapts a PanelView Plus 1250 (or PV1000/1000E) Keypad
Terminal to a PanelView 1200/1400E Keypad Cutout
2711P-RAT12E2 Adapts a PanelView Plus 1250 (or PV1000/1000E) Touch
Terminal to a PanelView 1200E Touch Cutout
2711P-RAT12E Adapts a PanelView Plus 1250 (or PV1000/1000E) Touch
Terminal to a PanelView 1400E Touch Cutout
2711P-RAK12S Adapts a PanelView Plus 1250 (or PV1000/1000E) Keypad
Terminal to a PanelView Standard 1400 Keypad Cutout
2711P-RAT12S Adapts a PanelView Plus 1250 (or PV1000/1000E) Touch
Terminal to a PanelView Standard 1400 Touch Cutout
2711P-RAK15 Adapts a PanelView Plus 1500 Keypad or Keypad & Touch
Terminal to a PanelView 1200E/1400E Keypad Terminal
2711P-RAT15 Adapts a PanelView Plus 1500 Touch Terminal to a PanelView
1400E Touch Cutout
Cat. No. Description
2711P-EX04 Ethernet CAT5 Crossover Cable, Industrial Grade, 4.3 m (14 ft)
2711-NC13 RS-232 Operating Cable (9-pin D-Shell to 9-pin D-Shell), 5 m (16.4 ft)
2711-NC14 RS-232 Operating/Programming Cable (9-pin D-Shell to 9-pin D-Shell), 10 m
(32.7 ft)
2711-NC21 RS-232 Operating Cable (9-pin D-Shell to 8-pin Mini DIN), 5 m (16.4 ft)
2711-NC22 RS-232 Operating Cable (9-pin D-Shell to 8-pin Mini DIN), 10 m (32.7 ft)
1761-CBL-AS03 DH-485 Operating Cable, 3 m (10 ft)
1761-CBL-AS09 DH-485 Operating Cable, 9 m (30 ft)
Cat. No. Description
1761-NET-AIC AIC+ Advanced Interface Converter
1747-AIC Isolated Link Coupler with DH-485 Communication Module (2711P-RN6)
