Lift and Mount the Drive Chapter 3
Figure 17 - IP54, NEMA/UL Type 12, Wall Mount Frames 2…5, Bottom Access
Dimensions are in millimeters and (inches).
179.4
(7.06)
146.4
(5.76)
109.4
(4.31)
88.1 (3.47)
85.7 (3.37)
65.1 (2.56)
44.5 (1.75)
42.1 (1.66)
136.5
(5.37)
183.5
(7.22)
49.8 (1.96)
62.3 (2.45)
92.8 (3.65)
123.3 (4.85)
135.8 (5.35)
136.5
(5.37)
182.0
(7.17)
51.8 (2.04)
76.8 (3.02)
108.8 (4.28)
140.8 (5.54)
165.8 (6.53)
141.9
(5.59)
181.9
(7.16)
52.8 (2.08)
92.8 (3.65)
132.8 (5.23)
172.8 (6.80)
212.8 (8.38)
2x: Ø22.0
(Ø0.87)
2x: Ø43.7
(Ø1.72)
2x: Ø50.0
(Ø1.97)
2x: Ø43.7
(Ø1.72)
3x: Ø29.0
(Ø1.14)
3x: Ø22.2
(Ø0.87)
3x: Ø22.2
(Ø0.87)
3x: Ø22.2
(Ø0.87)
Wall Mount Frame 2
Wall Mount Frame 3
Wall Mount Frame 4
Wall Mount Frame 5
