Allen-Bradley PowerFlex 20-750-ENC-1

Rockwell Automation Publication 750-IN001O-EN-P - October 2014 57
Lift and Mount the Drive Chapter 3
Figure 19 - Flange Mount, Frame 3
Dimensions are in millimeters and (inches).
260.0
(10.24)
212.0
(8.35)
515.0
(20.28)
142.8
(5.62)
37.8
(1.48)
247.8
(9.76)
352.8
(13.89)
457.8
(18.02)
495.5
(19.51)
32.3 (1.27)
120.3 (4.74)
208.3 (8.20)
240.5 (9.47)
16x: Ø3.50
(Ø0.138)
4x: 5.00R
(0.197R)
179.00 +1.80/-0.00
(7.047 +0.070/-0.000)
434.00 +1.80/-0.00
(17.087 +0.070/-0.000)
84.6
(3.33)
30.75
(1.211)
30.75
(1.211)
IMPORTANT
Must use mounting hardware supplied to meet enclosure rating.
