72 Rockwell Automation Publication 750-IN001O-EN-P - October 2014
Chapter 3 Lift and Mount the Drive
Figure 34 - IP54, NEMA 12, MCC Style Cabinet, Floor Mount Frame 8 (Enclosure Codes K and Y)
IP54, UL Type 12, MCC Style Cabinet, Floor Mount Frame 8 (Enclosure Code J)
M12 (1/2 in.) Property Class 8.8 anchoring hardware recommended to
fasten the drive cabinet through its internal mounting angle to the
foundation. Anchor bolts may be pre-located and embedded in the
foundation prior to instillation.
2477
(97.5)
800
(31.5)
600
(23.6)
2300
(90.6)
898
(35.4)
240
(9.4)
1374
(54.1)
300
(11.8)
531
(20.9)
ø18.0
(0.71)
742
(29.2)
43
(1.7)
69
(2.7)
76
(3.0)
➊
➋
➍
➌
680
(26.8)
547
(21.5)
1464
(57.6)
127
(5.0)
292
(11.5)
440
(17.3)
127
(5.0)
76
(3.0)
➋
No. Description
➊ Power wiring conduit plates.
➋ Control wiring conduit plates.
➌ Optional HIM.
➍ Recommended three-hole anchoring.
BOTTOM
BOTTOM
TOP
