20 Rockwell Automation Publication 22-TD001I-EN-P - June 2013
PowerFlex 4 and 40 AC Drives
Drive Ratings — PowerFlex 40
Catalog Number
Output Ratings Input Ratings Branch Circuit Protection Power Dissipation
kW (HP) Amps
Voltage
Range kVA Amps Fuses
(2)
(2) Recommended Fuse Type: UL Class J, CC, T or Type BS88; 600V (550V) or equivalent.
140M Motor
Protectors
(3)
(4)
(3) The AIC ratings of the Bulletin 140M Motor Protector Circuit Breakers may vary. See Bulletin 140M Motor Protection Circuit Breakers Application Ratings.
(4) Manual Self-Protected (Type E) Combination Motor Controller, UL listed for 208 Wye or Delta, 240 Wye or Delta, 480Y/277 or 600Y/347. Not UL listed for use on 480V or 600V Delta/Delta, corner ground,
or high-resistance ground systems.
Contactors
Min. Enclosure
Volume
(5)
(in.
3
)
(5) When using a Manual Self-Protected (Type E) Combination Motor Controller, the drive must be installed in a ventilated or non-ventilated enclosure with the minimum volume specified in this column.
Application specific thermal considerations may require a larger enclosure.
Internal Total
100…120V AC – 1-Phase Input, 0…230V 3-Phase Output
22B-V2P3N104 0.4 (0.5) 2.3 90…132 1.15 9.0 15 140M-C2E-C16 100-C12 1655 9 30
22B-V5P0N104 0.75 (1.0) 5.0 90…132 2.45 20.3 35 140M-D8E-C20 100-C23 1655 12 55
22B-V6P0N104 1.1 (1.5) 6.0 90…132 3.0 24.0 40 140M-F8E-C32 100-C37 1655 12 70
200…240V AC – 1-Phase Input, 0…230V 3-Phase Output
(1)
(1) 200…240V AC - 1-Phase drives are also available with an integral EMC filter. Catalog suffix changes from N104 to N114 or N103 to N113.
22B-A2P3N104 0.4 (0.5) 2.3 180…264 1.15 6.0 10 140M-C2E-B63 100-C09 1655 9 30
22B-A5P0N104 0.75 (1.0) 5.0 180…264 2.45 12.0 20 140M-C2E-C16 100-C12 1655 12 55
22B-A8P0N104 1.5 (2.0) 8.0 180…264 4.0 18.0 30 140M-D8E-C20 100-C23 1655 16 80
22B-A012N104 2.2 (3.0) 12.0 180…264 5.5 25.0 40 140M-F8E-C32 100-C37 2069 11 110
200…240V AC – 3-Phase Input, 0…230V 3-Phase Output
22B-B2P3N104 0.4 (0.5) 2.3 180…264 1.15 2.5 6 140M-C2E-B40 100-C07 1655 9 30
22B-B5P0N104 0.75 (1.0) 5.0 180…264 2.45 5.7 10 140M-C2E-C10 100-C09 1655 12 55
22B-B8P0N104 1.5 (2.0) 8.0 180…264 4.0 9.5 15 140M-C2E-C16 100-C12 1655 16 80
22B-B012N104 2.2 (3.0) 12.0 180…264 5.5 15.5 25 140M-C2E-C16 100-C23 1655 16 115
22B-B017N104 3.7 (5.0) 17.5 180…264 8.6 21.0 35 140M-F8E-C25 100-C23 1655 16 165
22B-B024N104 5.5 (7.5) 24.0 180…264 11.8 26.1 40 140M-F8E-C32 100-C37 2069 28 225
22B-B033N104 7.5 (10.0) 33.0 180…264 16.3 34.6 60 140M-F8E-C45 100-C60 2069 28 290
380…480V AC – 3-Phase Input, 0…460V 3-Phase Output
22B-D1P4N104 0.4 (0.5) 1.4 342…528 1.4 1.8 3 140M-C2E-B25 100-C07 1655 15 30
22B-D2P3N104 0.75 (1.0) 2.3 342…528 2.3 3.2 6 140M-C2E-B40 100-C07 1655 13 40
22B-D4P0N104 1.5 (2.0) 4.0 342…528 4.0 5.7 10 140M-C2E-B63 100-C09 1655 13 60
22B-D6P0N104 2.2 (3.0) 6.0 342…528 5.9 7.5 15 140M-C2E-C10 100-C09 1655 17 90
22B-D010N104 4.0 (5.0) 10.5 342…528 10.3 13.0 20 140M-C2E-C16 100-C23 1655 14 150
22B-D012N104 5.5 (7.5) 12.0 342…528 11.8 14.2 25 140M-D8E-C20 100-C23 2069 23 160
22B-D017N104 7.5 (10.0) 17.0 342…528 16.8 18.4 30 140M-D8E-C20 100-C23 2069 24 200
22B-D024N104 11.0 (15.0) 24.0 342…528 23.4 26.0 50 140M-F8E-C32 100-C43 2069 25 285
460…600V AC – 3-Phase Input, 0…575V 3-Phase Output
22B-E1P7N104 0.75 (1.0) 1.7 414…660 2.1 2.3 6 140M-C2E-B25 100-C09 1655 13 40
22B-E3P0N104 1.5 (2.0) 3.0 414…660 3.65 3.8 6 140M-C2E-B40 100-C09 1655 13 60
22B-E4P2N104 2.2 (3.0) 4.2 414…660 5.2 5.3 10 140M-D8E-B63 100-C09 1655 17 90
22B-E6P6N104 4.0 (5.0) 6.6 414…660 8.1 8.3 15 140M-D8E-C10 100-C09 1655 14 150
22B-E9P9N104 5.5 (7.5) 9.9 414…660 12.1 11.2 20 140M-D8E-C16 100-C16 2069 23 160
22B-E012N104 7.5 (10.0) 12.2 414…660 14.9 13.7 25 140M-D8E-C16 100-C23 2069 24 200
22B-E019N104 11.0 (15.0) 19.0 414…660 23.1 24.1 40 140M-F8E-C25 100-C30 2069 25 285
