Allen-Bradley PowerFlex 4 Original Instructions

36 Rockwell Automation Publication 22-TD001I-EN-P - June 2013
PowerFlex 4 and 40 AC Drives
Enclosure Options and Approximate Dimensions
355.6
(14.00)
9.4
(0.37)
393.2
(15.48)
405.9
(15.98)
336.6
(13.25)
298.5
(11.75)
177.8
(7.00)
69.3
(2.73)
355.1
(13.98)
342.4
(13.48)
304.8
(12.00)
285.8
(11.25)
Optional mounting bracket orientation.
6.35
(0.25)
Aotewell Ltd
www.aotewell.com
Industry Automation
HongKong|UK|China
sales@aotewell.com
+86-755-8660-6182
http://www.aotewell.com/

Allen-Bradley PowerFlex 4 Specifications

General

Series	PowerFlex 4
Horsepower	0.2-3 HP
Enclosure	IP20
Output Frequency	0-400 Hz
Power Range	0.2…2.2 kW (0.25…3 HP)
Communication Options	RS-485
Storage Temperature	-40…85 °C (-40…185 °F)
Relative Humidity	5-95% non-condensing
Control Method	Volts per Hertz
