Allen-Bradley PowerFlex 4 - Start and Speed Reference Control

28 Rockwell Automation Publication 22-TD001I-EN-P - June 2013
PowerFlex 4 and 40 AC Drives
IP 30, NEMA/UL Type 1 Option Kit without Communication Options
33.0
(1.30)
74.3
(2.93)
109.9
(4.33)
64.1 (2.52)
79.1 (3.11)
 22.2
(0.87)
25.6 (1.01)
40.6 (1.60)
59.2
(2.33)
40.0
(1.57)
20.7
(0.81)
75.3
(2.96)
34.0
(1.34)
 22.2
(0.88)
33.0
(1.30)
Frame B — 22-JBAB
60.0
(2.36)
111.2
(4.38)
152.2
(5.99)
107.0 (4.21)
66.0 (2.60)
 22.2
(0.87)
 28.5
(1.12)
24.0 (0.94)
Frame C — 22-JBAC
Frame A — 22-JBAA
PowerFlex 4 uses Frames A and B. PowerFlex 40 uses Frames B and C.
64.0
(2.52)
25.0
(0.98)
 22.2
(0.87)
76.3
(3.00)
105.3
(4.15)
134.3
(5.29)
50.0 (1.97)
77.5 (3.05)
22.5 (0.89)
Frame B — 22-JBCB
25.0
(0.98)
45.7 (1.80)
109.8
(4.32)
144.8
(5.70)
179.8
(7.08)
69.2 (2.72)
92.2 (3.63)
108.7 (4.28)
22.2 (0.87)
 22.2
(0.87)
 28.5
(1.12)
60.0
(2.36)
Frame C — 22-JBCC
PowerFlex 40 IP 30/NEMA 1/UL Type 1 Option Kit with Communication Option
Shaded areas are applicable to PowerFlex 40 only.
