Allen-Bradley PowerFlex 4 Original Instructions

Rockwell Automation Publication 22-TD001I-EN-P - June 2013 27
PowerFlex 4 and 40 AC Drives
Flange Mount Drive Continued
IP 66, NEMA/UL Type 4X/12
138.2
(5.44)
105.8
(4.17)
325
(12.8)
300
(11.81)
130.3
(5.13)
291.5
(11.48)
164
(6.46)
180
(7.09)
90
(3.54)
307.5
(12.11)
230.6
(9.08)
153.8
(6.06)
76.9
(3.03)
8
(0.31)
8
(0.31)
5.3
(0.21)
22B-CCC
Frame C—PowerFlex 40 only
165
(6.50)
146
(5.75)
6.5
(0.26)
270
(10.63)
253
(9.96)
82.5
(3.25)
46
(1.81)
23
(0.91)
89
(3.50)
124
(4.88)
198
(7.80)
28
(1.10)
22
(0.87)
Frame B—PowerFlex 40 only
Shaded areas are applicable to PowerFlex 40 only.
