Code Voltage Ph.
V 120V AC 1
A 240V AC 1
B 240V AC 3
D 480V AC 3
Code Version
3 No Brake IGBT
4 Standard
Code Interface Module
1 Fixed Keypad
Code Enclosure
N Panel Mount - IP 20 (NEMA Type Open)
F Flange Mount - IP 20 (NEMA Type Open)
H Replacement Plate Drive - IP 20 (NEMA Type Open)
- Contact factory for ordering information.
1-3 4 5 6-8 9 10 11 12
(1)
13-14
22A - A 1P5 N 1 1 4 AA
Drive Dash Voltage Rating Rating Enclosure HIM Emission Class Type Optional
Output Current @ 100-120V Input
Code Amps kW (HP)
1P5 1.5 0.2 (0.25)
2P3 2.3 0.4 (0.5)
4P5 4.5 0.75 (1.0)
6P0 6.0 1.1 (1.5)
Code Rating
0 Not Filtered
1Filtered
Code
22A PowerFlex 4
Code Purpose
AA Reserved for
thru custom firmware
ZZ
Output Current @ 200-240V Input, NO BRAKE
Code Amps kW (HP)
1P4 1.4 0.2 (0.25)
2P1 2.1 0.4 (0.5)
3P6 3.6 0.75 (1.0)
6P8 6.8 1.5 (2.0)
9P6 9.6 2.2 (3.0)
Output Current @ 380-480V Input
Code Amps kW (HP)
1P4 1.4 0.4 (0.5)
2P3 2.3 0.75 (1.0)
4P0 4.0 1.5 (2.0)
6P0 6.0 2.2 (3.0)
8P7 8.7 3.7 (5.0)
Output Current @ 200-240V Input
Code Amps kW (HP)
1P5 1.5 0.2 (0.25)
2P3 2.3 0.4 (0.5)
4P5 4.5 0.75 (1.0)
8P0 8.0 1.5 (2.0)
012 12.0 2.2 (3.0)
017 17.5 3.7 (5.0)
(1)
Position 12 of the Catalog Number now indicates drive type. All PowerFlex 4 drives
are equipped with RS485 communication.
To Next Page
