Allen-Bradley PowerFlex 4 User Manual

Appendix B
Accessories and Dimensions
Table B.A Catalog Number Description
Table B.B PowerFlex 4 Drives
For information on… See page
Product Selection
B-1
Product Dimensions B-5
Product Selection
22A - A 1P5 N 1 1 4
Drive Voltage Rating Rating Enclosure HIM Emission Class Type
Drive Ratings Catalog Number
Frame
SizeInput Voltage kW HP
Output
Current Panel Mount Flange Mount
(1)
(1)
Replacement Plate drives are also available. Contact factory for ordering information.
120V 50/60 Hz
1-Phase
No Filter
0.2 0.25 1.5A 22A-V1P5N104 22A-V1P5F104 A
0.4 0.5 2.3A 22A-V2P3N104 22A-V2P3F104 A
0.75 1.0 4.5A 22A-V4P5N104 22A-V4P5F104 B
1.1 1.5 6.0A 22A-V6P0N104 22A-V6P0F104 B
240V 50/60 Hz
1-Phase
NO BRAKE
With Integral “S Type”
EMC Filter
0.2 0.25 1.4A 22A-A1P4N113 – A
0.4 0.5 2.1A 22A-A2P1N113 – A
0.75 1.0 3.6A 22A-A3P6N113 – A
1.5 2.0 6.8A 22A-A6P8N113 – B
2.2 3.0 9.6A 22A-A9P6N113 – B
240V 50/60 Hz
1-Phase
NO BRAKE
No Filter
0.2 0.25 1.4A 22A-A1P4N103 22A-A1P4F103 A
0.4 0.5 2.1A 22A-A2P1N103 22A-A2P1F103 A
0.75 1.0 3.6A 22A-A3P6N103 22A-A3P6F103 A
1.5 2.0 6.8A 22A-A6P8N103 22A-A6P8F103 B
2.2 3.0 9.6A 22A-A9P6N103 22A-A9P6F103 B
240V 50/60 Hz
1-Phase
With Integral “S Type”
EMC Filter
0.2 0.25 1.5A 22A-A1P5N114 – A
0.4 0.5 2.3A 22A-A2P3N114 – A
0.75 1.0 4.5A 22A-A4P5N114 – A
1.5 2.0 8.0A 22A-A8P0N114 – B
240V 50/60 Hz
1-Phase
No Filter
0.2 0.25 1.5A 22A-A1P5N104 22A-A1P5F104 A
0.4 0.5 2.3A 22A-A2P3N104 22A-A2P3F104 A
0.75 1.0 4.5A 22A-A4P5N104 22A-A4P5F104 A
1.5 2.0 8.0A 22A-A8P0N104 22A-A8P0F104 B
240V 50/60 Hz
3-Phase
No Filter
0.2 0.25 1.5A 22A-B1P5N104 22A-B1P5F104 A
0.4 0.5 2.3A 22A-B2P3N104 22A-B2P3F104 A
0.75 1.0 4.5A 22A-B4P5N104 22A-B4P5F104 A
1.5 2.0 8.0A 22A-B8P0N104 22A-B8P0F104 A
2.2 3.0 12.0A 22A-B012N104 22A-B012F104 B
3.7 5.0 17.5 22A-B017N104 22A-B017F104 B
480V 50/60 Hz
3-Phase
No Filter
0.4 0.5 1.4A 22A-D1P4N104 22A-D1P4F104 A
0.75 1.0 2.3A 22A-D2P3N104 22A-D2P3F104 A
1.5 2.0 4.0A 22A-D4P0N104 22A-D4P0F104 A
2.2 3.0 6.0A 22A-D6P0N104 22A-D6P0F104 B
3.7 5.0 8.7A 22A-D8P7N104 22A-D8P7F104 B

Allen-Bradley PowerFlex 4 Specifications

General

Series	PowerFlex 4
Horsepower	0.2-3 HP
Enclosure	IP20
Output Frequency	0-400 Hz
Power Range	0.2…2.2 kW (0.25…3 HP)
Communication Options	RS-485
Storage Temperature	-40…85 °C (-40…185 °F)
Relative Humidity	5-95% non-condensing
Control Method	Volts per Hertz
