Allen-Bradley PowerFlex 4 User Manual

RJ45 DSI Splitter Cable D-3
Connecting an RS-485 Network
AK-U0-RJ45-TR1
Terminating Resistor
(end of network)
AK-U0-RJ45-TB2P
Two-position
Terminal Block
DSI / MDI Drives
or
or
Customer supplied RJ45 male-to-RJ45 male
cables with wires connected at pins 4 and 5 only.
Both the Master (M) and Slave (S) ports on the RJ45 Splitter
Cable operate as standard RS-485 ports in this configuration.
