Appendix D
RJ45 DSI Splitter Cable
The PowerFlex 4 drive provides a RJ45 port to allow the connection of a
single peripheral device. The RJ45 DSI Splitter Cable can be used to
connect a second DSI peripheral device to the drive.
Connectivity Guidelines
Two peripherals maximum can be attached to a drive.
If a single peripheral is used, it must be connected to the Master port
(M) on the splitter and configured for “Auto” (default) or “Master.”
Parameter 9 [Device Type] on the DSI / MDI keypads and Parameter
1 [Adapter Cfg] on the Serial Converter are used to select the type
(Auto / Master / Slave).
If two peripherals will be powered up at the same time, one must be
configured as the “Master” and connected to the Master port (M) and
the other must be connected as the “Slave” and connected to the
Slave port (S).
ATTENTION: Risk of injury or equipment damage exists. The
peripherals may not perform as intended if these Connectivity
Guidelines are not followed. Precautions should be taken to follow
these Connectivity Guidelines.
