Rockwell Automation Publication 22-TD001I-EN-P - June 2013 23
PowerFlex 4 and 40 AC Drives
A055 Relay Out Sel 13 different settings for a variety of drive status conditions Ready/Fault
24 different settings for a variety of drive status conditions Ready/Fault
A056 Relay Out Level 0.0 to 9999 0.0
A058 Opto Out1 Sel 24 settings; Ready/Fault, At Frequency, Motor Running, Reverse, Motor Overload, Ramp Regulator, Above Frequency,
Above Current, Above DC Voltage, Retries Exceeded, Above Analog Voltage, Logic In1, Logic In2, Logic 1 & 2, Logic 1 or
2, Step Logic Out, Timer Out, Counter Out, Above PF Angle, Analog Input Loss, Param Control, Non-Recoverable Fault,
EM Brake Control, Above Frequency Command
MotorRunning
A059 Opto Out1 Level 0.0 to 9999 0.0
A061 Opto Out2 Sel 24 settings; Ready/Fault, At Frequency, Motor Running, Reverse, Motor Overload, Ramp Regulator, Above Frequency,
Above Current, Above DC Voltage, Retries Exceeded, Above Analog Voltage, Logic In1, Logic In2, Logic 1 & 2, Logic 1 or
2, Step Logic Out, Timer Out, Counter Out, Above PF Angle, Analog Input Loss, Param Control, Non-Recoverable Fault,
EM Brake Control, Above Frequency Command
At Frequency
A062 Opto Out2 Level 0.0 to 9999 0.0
A064 Opto Out Logic Determines the logic (NO or NC) of the opto outputs, 4 settings - NO/NO, NC/NO, NO/NC, NC/NC NO/NO
A065 Analog Out Sel Sets the analog output signal mode, various settings Output Freq 0…10, 0V=0Hz
A066 Analog Out High 0 to 800% 100%
A067 Accel Time 2 0.0 to 600.0 seconds 20.0 Secs
A068 Decel Time 2 0.1 to 600.0 seconds 20.0 Secs
A069 Internal Freq 0.0 to 240.0 Hz 60.0 Hz
0.0 to 400.0 Hz 60.0 Hz
A070 Preset Freq 0 0.0 to 240.0 Hz 0.0 Hz
0.0 to 400.0 Hz 0.0 Hz
A071 Preset Freq 1 0.0 to 240.0 Hz 5.0 Hz
0.0 to 400.0 Hz 5.0 Hz
A072 Preset Freq 2 0.0 to 240.0 Hz 10.0 Hz
0.0 to 400.0 Hz 10.0 Hz
A073 Preset Freq 3 0.0 to 240.0 Hz 20.0 Hz
0.0 to 400.0 Hz 20.0 Hz
A074 Preset Freq 4 0.0 to 400.0 Hz 30.0 Hz
A075 Preset Freq 5 0.0 to 400.0 Hz 40.0 Hz
A076 Preset Freq 6 0.0 to 400.0 Hz 50.0 Hz
A077 Preset Freq 7 0.0 to 400.0 Hz 60.0 Hz
A078 Jog Frequency 0.0 to (Value set in P035 [Maximum Freq] 10.0 Hz
A079 Jog Accel/Decel 0.1 to 600.0 seconds 10.0 Secs
A080 DC Brake Time 0.0 to 90.0 seconds 0.0 Secs
0.0 to 99.9 seconds 0.0 Secs
A081 DC Brake Level 0.0 to (Drive Rated Amps x 1.8) Drive Rated Amps x 0.05
A082 DB Resistor Sel Used to set percent duty cycle for external dynamic braking Disabled
A083 S Curve % 0 to 100% 0% (Disabled)
A084 Boost Select 14 boost settings (in % of P031 [Motor NP Volts]), redefines the Volts per Hertz curve 5.0 (2.5 for 5 HP drives)
15 boost settings (in % of P031 [Motor NP Volts]), redefines the Volts per Hertz curve 5.0, CT (2.5 CT for
5…15 HP drives)
A085 Start Boost 0.0 to 25.0% 2.5%
A086 Break Voltage 0.0 to 100.0% 25.0%
A087 Break Frequency 0.0 to 400.0 Hz 15.0 Hz
A088 Maximum Voltage 20 to Drive Rated Volts Drive Rated Volts
A089 Current Limit 1 0.1 to (Drive Rated Amps x 1.8) Drive Rated Amps x 1.5
A090 Motor OL Select 3 settings; No Derate, Minimum Derate, Maximum Derate No Derate
A091 PWM Frequency 2.0 to 16.0 kHz 4.0 kHz
A092 Auto Rstrt Tries 0 to 9 0
A093 Auto Rstrt Delay 0.0 to 300.0 seconds 1.0 Secs
A094 Start At PowerUp 2 settings; Disabled, Enabled Disabled
A095 Reverse Disable 2 settings; Reverse Enabled, Reverse Disabled Rev Enabled
Parameter
Number Parameter Name Description Factory Default
Shaded areas are applicable to PowerFlex 40 only.
