24 Rockwell Automation Publication 22-TD001I-EN-P - June 2013
PowerFlex 4 and 40 AC Drives
Parameter
Number Parameter Name Description Factory Default
Advanced Program Group, Continued
A096 Flying Start En 2 settings; Disabled, Enabled Disabled
A097 Compensation 4 settings; Disabled, Electrical, Mechanical, Both Electrical
A098 SW Current Trip Software instantaneous trip, 0.0 to (Drive Rated Amps x 2) 0.0 (Disabled)
A099 Process Factor 0.1 to 999.9 30.0
A100 Fault Clear Resets a fault and clears the fault queue Ready/Idle
A101 Program Lock Protects parameters against change by unauthorized personnel Unlocked
A102 Testpoint Sel Used by Rockwell Automation field service personnel 400
A103 Comm Data Rate 6 settings; 1200, 2400, 4800, 9600, 19.2K, 38.4K 9600
A104 Comm Node Addr 1 to 247 100
A105 Comm Loss Action 4 settings; Fault, Coast to Stop, Stop, Continue Last Speed Fault
A106 Comm Loss Time 0.1 to 60.0 seconds 5.0 Secs
A107 Comm Format 6 settings; RTU 8-N-1, RTU 8-E-1, RTU 8-O-1, RTU 8-N-2, RTU 8-E-2, RTU 8-O-2 RTU 8-N-1
A108 Language 10 settings; English, Francais, Espanol, Italiano, Deutsch, Reserved, Portugues, Reserved, Reserved, Nederlands English
A109 Anlg Out Setpt 0.0/100.0% 100.0%
A110 Anlg In 0-10V Lo 0.0 to 100.0% 0.0%
A111 Anlg In 0-10V Hi 0.0 to 100.0% 100.0%
A112 Anlg In4-20mA Lo 0.0 to 100.0% 0.0%
A113 Anlg In4-20mA Hi 0.0 to 100.0% 100.0%
A114 Slip Hertz @ FLA 0.0 to 10.0 Hz 2.0 Hz
A115 Process Time Lo 0.00 to 99.99 0.00
A116 Process Time Hi 0.00 to 99.99 0.00
A117 Bus Reg Mode 0/1 Enabled
A118 Current Limit 2 0.1 to (Drive Rated Amps x 1.8) Drive Rated Amps x 1.5
A119 Skip Frequency 0 to 400 Hz 0 Hz
A120 Skip Freq Band 0.0 to 30.0 Hz 0.0 Hz
A121 Stall Fault Time 6 settings; 60 Seconds, 120 Seconds, 240 Seconds, 360 Seconds, 480 Seconds, Fit Disabled 60 Seconds
A122 Analog In Loss 7 settings; Disabled, Fault (F29), Stop, Zero Ref, Min Freq Ref, Max Freq Ref, Int Freq Ref Disabled
A123 10V Bipolar Enbl 2 settings; Uni-Polar In, Bi-Polar In Uni-Polar In
A124 Var PWM Disable 2 settings; Enabled, Disabled Enabled
A125 Torque Perf Mode 2 settings; V/Hz, Sensorless Vector Sensrls Vect
A126 Motor NP FLA Drive Rated Amps x 0.1/2 Drive Rated Amps
A127 Autotune 3 settings; Ready/Idle, Static Tune, Rotate Tune Ready/Idle
A128 IR Voltage Drop 0.0 to 230.0 VAC Based on Drive Rating
A129 Flux Current Ref 0.00 to Motor NP FLA Based on Drive Rating
A130 PID Trim Hi 0.0 to 400.0 60.0
A131 PID Trim Lo 0.0 to 400.0 0.0
A132 PID Ref Sel 9 settings; PID Disabled, PID Setpoint, 0…10V Input, 4…20 mA Input, Comm Port, Setpoint - Trim, 0…10V - Trim,
4…20 mA - Trim, Comm - Trim
PID Disabled
A133 PID Feedback Sel 3 settings; 0…10V Input, 4…20 mA Input, Comm Port 0…10V Input
A134 PID Prop Gain 0.00 to 99.99 0.01
A135 PID Integ Time 0.0 to 999.9 Seconds 0.1 Secs
A136 PID Diff Rate 0.00 to 99.99 (1/Secs) 0.01 (1/Secs)
A137 PID Setpoint 0.0 to 100.0% 0.0%
A138 PID Deadband 0.0 to 10.0% 0.0%
A139 PID Preload 0.0 to 400.0 Hz 0.0 Hz
A140…A147 Stp Logic 0-7 0001 to bAFF 00F1
A150…157 Stp Logic Time 0-7 0.0 to 999.9 Seconds 30.0 Secs
A160 EM Brk Off Delay 0.01/10.00 Secs 2.00 Secs
A161 EM Brk On Delay 0.01/10.00 Secs 2.00 Secs
A162 MOP Reset Sel 2 settings; Zero MOP Ref, Save MOP Ref Save MOP Ref
A163 DB Threshold 0.0 to 110.0% 100.0%
A164 Comm Write Mode 2 settings; Save, RAM Only Save
A165 Anlg Loss Delay 0.0 to 20.0 Secs 0.0 Secs
A166 Analog In Filter 0 to 14 0
Shaded areas are applicable to PowerFlex 40 only.
