Rockwell Automation Publication 520-UM001G-EN-E - September 2014 73
Programming and Parameters Chapter 3
Basic Display Group (continued)
b013 [Contrl In Status] Related Parameter(s): b002, P044, P045
State of the digital terminal blocks 1...3 and DB transistor.
Values Default: Read Only
Min/Max: 0000/1111
Display: 0000
Actual control commands may come from a source other than the control terminal block.
1 = Closed State, 0 = Open State
DigIn TBlk 1 Digit 1
DigIn TBlk 2 Digit 2
DigIn TBlk 3 Digit 3
DB Trans On
(1)
Digit 4
(1) The DB Transistor “on” indication must have a 0.5 s hysteresis. It will turn on and stay
on for at least 0.5 s every time the DB transistor is turned on.
Not Used
b014 [Dig In Status] Related Parameter(s): t065-t068
State of the programmable digital inputs.
Values Default: Read Only
Min/Max: 0000/1111
Display: 0000
1 = Closed State, 0 = Open State
DigIn TBlk 5 Digit 1
DigIn TBlk 6 Digit 2
DigIn TBlk 7
(1)
Digit 3
(1) Setting is specific to PowerFlex 525 drives only.
DigIn TBlk 8
(1)
Digit 4
Not Used
b015 [Output RPM] Related Parameter(s): P035
Current output frequency in rpm. Scale is based on P035 [Motor NP Poles].
Values Default: Read Only
Min/Max: 0/24000 rpm
Display: 1 rpm
b016 [Output Speed] Related Parameter(s): P044
Current output frequency in %. Scale is 0% at 0.00 Hz to 100% at P044 [Maximum Freq].
Values Default: Read Only
Min/Max: 0.0/100.0%
Display: 0.1%
b017 [Output Power] Related Parameter(s): b018
Output power present at T1, T2 & T3 (U, V & W).
Values Default: Read Only
Min/Max: 0.00/(Drive Rated Power x 2)
Display: 0.01 kW
