Allen-Bradley PowerFlex 523 User Manual

Rockwell Automation Publication 520-UM001G-EN-E - September 2014 77
Programming and Parameters Chapter 3
Basic Program Group (continued)
P034 [Motor NP FLA] Related Parameter(s): P040
Sets the motor nameplate FLA. Used to assist the Autotune routine and motor control.
Values Default: Based on Drive Rating
Min/Max: 0.1/(Drive Rated Amps x 2)
Display: 0.1 A
P035 [Motor NP Poles] Related Parameter(s): b015
Sets the number of poles in the motor.
Values Default: 4
Min/Max: 2/40
Display: 1
P036 [Motor NP RPM]
Stop drive before changing this parameter.
Sets the rated nameplate rpm of the motor. Used to calculate the rated slip of the motor. To reduce the slip frequency, set this parameter closer to the motor synchronous speed.
Values Default: 1750 rpm
Min/Max: 0/24000 rpm
Display: 1 rpm
P037 [Motor NP Power]
PowerFlex 525 only.
Sets the motor nameplate power. Used in PM regulator.
Values Default: Drive Rated Power
Min/Max: 0.00/Drive Rated Power
Display: 0.01 kW
PF 525
P038 [Voltage Class]
Stop drive before changing this parameter.
Sets the voltage class of 600V drives. Only applicable to 600V drives.
Options 2 “480V”
3 “600V” (Default)
P039 [Torque Perf Mode] Related Parameter(s): P040, A530, A531, A532, A533
Stop drive before changing this parameter.
Selects the motor control mode.
Options 0 “V/Hz”
1 “SVC” (Default)
2 “Economize”
3“Vector”
(1)
(1) Setting is specific to PowerFlex 525 drives only.

Allen-Bradley PowerFlex 523 Specifications

General

Frequency	50/60 Hz
Dimensions	Varies by model
Weight	Varies by model
Output Voltage	0 to Input Voltage
Power Rating	0.4-22 kW
Control Method	Sensorless Vector Control
Enclosure	IP20
Communication	EtherNet/IP
Operating Temperature	-20 to 50°C (-4 to 122°F)
Storage Temperature	-40 to 85°C (-40 to 185°F)
Relative Humidity	5% to 95% (non-condensing)
Input Voltage	200-240V AC, 380-480V AC
Horsepower	0.5…30 Hp
